WWC ViperHiTemp Flexible Cable Double Insulated High Temperature 11 Core & Earth 1.5mm 450/750V Silicone +180C Black

Description

Flexible Cable, Double Insulated, High Temperature, 11 Core & Earth, 1.5 mm, Tinned Annealed Copper, 450/750 Volt, 0.2 mm Strands, 2.9 mm Core Diameter, 14.9 mm Overall Diameter, 74.5 mm Bend Radius, Conductor Resistance: DC - 13.7 Ohm/km, Silicone Rubber Insulation, Silicone Rubber Sheath, Black with White Numbered Green/Yellow Cores, Black Sheath, -60 to 180 deg C

Key Specifications

SKU	WWC6215
Brand	WWC
Range Name	ViperHiTemp
Product Type	Flexible Cable High Temperature Double Insulated

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	100
UNSPSC Class	26121600
UOM	MTR
Vendor Product	6215
Bend Radius	74.5 mm
Conductor Resistance	DC: 13.7 Ohm/km
Conductor Size	1.5 mm
Core Colours	Green/Yellow/Black/White Numerals
Core Diameter	2.9 mm
Conductor Type	Tinned Annealed Copper
Insulation Material	Silicone Rubber
Overall Diameter	14.9 mm
Number of Cores	11 Core + Earth
Sheath Colour	Black
Sheath Material	Silicone Rubber
Temperature	-60 to 180 deg C
Stranding	0.2 mm
Voltage	450-750 Volt
