Wideband Fibre Optic Distribution Cable Multimode Indoor OM3 16 Fibre LSZH Aqua
Loading...
Description
Fibre Optic Distribution Cable Multimode Indoor, Fibre Optic Cable Multimode 16Core Om3 Indoor, Loaded: 170mm, Installed: 85mm Bend Radius, Fibre Count: 16, OM3 Fibre, Multimode Fibre, Short Term: 1320 N, Long Term: 660 N Max. Tensile Load, LSZH Sheath, Aqua Sheath,-10 to 60 deg C, 8.5mm Outside Diameter
Key Specifications
| SKU |
WIDDTMXGZ16AQ
|
|---|---|
| Brand |
Wideband
|
| Product Type |
Fibre Optic Distribution
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Features |
|
|---|---|
| Standard Pack Size | 50 |
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | DTMXGZ16AQ |
| Bend Radius | Loaded: 170mm/Installed: 85mm |
| Fibre Count | 16 |
| Fibre Mode | Multimode |
| Fibre Type | OM3 |
| Max. Tensile Load | Short Term: 1320 N/Long Term: 660 N |
| Outside Diameter | 8.5mm |
| Sheath Colour | Aqua |
| Sheath Material | LSZH |
| Temperature | -10 to 60 deg C |
