Thomas & Betts Hi-Flex Flexible Conduit Metal Liquid Tight Heavy Duty Oil Resistant 20mm 150M Steel/PVC Orange

Description

Flexible Conduit, Metal, Liquid Tight, Heavy Duty, Oil Resistant, 20 mm, 16.1 mm ID, 21.1 mm OD, 150 mtr, 65 mm Bend Radius, IP66, Steel, Galvanised Finish, PVC Sheath, Orange Sheath, -10 to 105 deg C

Key Specifications

Barcode (EAN-13)	9324652021611
SKU	T&BHLT020-O-150
Brand	Thomas & Betts
Range Name	Hi-Flex HLT
Product Type	Flex Conduit Liquid Tight

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	These conduits are typically used in installations where there are motion, vibration and bending requirements such as in manufacturing or processing plants or where a high level of mechanical protection is required for an indoor or outdoor cable installation Three grades of liquidtight jacketed metallic conduit are available to suit different types of environments
Standard Pack Size	150
UNSPSC Class	39131700
UOM	RO
Vendor Product	HLT020-O-150
Bend Radius	65mm
Conduit Size	20 mm
Inside Diameter	16.1mm
IP Rating	IP66
Outside Diameter	21.1mm
Temperature	-10 to 105 deg C
Sheath Colour	Orange
