Siemens Ozoflex H07 RN-F Heavy Duty Flexible Cable 2 Core 1.5mm 0.6/1kV Copper EPR/CSP Black

Description

Flexible Cable Heavy Duty, 1.5 mm, Stranded Copper, 0.6-1 kV, 2 Core, 30/0.25 mm Strands, 9.1 mm Overall Diameter, Static 36.4 mm Flexible 45.5 mm Bend Radius, 15 N/mm Tensile Strength, Brown/Blue Core, EPR Insulation, CSP Elastomer Sheath, Black Sheath, 90 deg C, AS/NZS 1125 AS/NZS 3191 AS/NZS 5000-1 AS/NZS 3008.1.1:2009

Key Specifications

SKU	SIE5DH2204-5
Brand	Siemens
Range Name	Ozoflex
Product Type	Flexible Cable Heavy Duty

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	500
UNSPSC Class	26121600
UOM	MTR
Vendor Product	5DH2204-5
Bend Radius	Static 36.4 mm - Flexible 45.5 mm
Conductor Size	1.5 mm
Conductor Type	Stranded Copper
Core Colours	Brown/Blue
Insulation Material	EPR
Number of Cores	2 Core
Overall Diameter	9.1 mm
Sheath Colour	Black
Sheath Material	CSP Elastomer
Standards	AS/NZS 1125 AS/NZS 3191 AS/NZS 5000-1 AS/NZS 3008.1.1:2009
Temperature	90 deg C
Stranding	30/0.25 mm
Tensile Strength	15 Nm
Voltage	0.6-1 kV
