Sprecher+Schuh Time Delay Relay Electronic DIN 35 Rail Mount 1CO Function L Impulse Converter 30s-10min 346/440V

Description

Time Delay Relay Electronic, 346/440 Volt AC, 1 mA, 5 VA AC, 0.5 Watt DC, 1CO, Timing Function: Function L Impulse Converter, Timing Range: 30 sec-10 min, 30000000 Mechanical, 200000 Electrical Cycles, Tightening Torque: 0.8-1.2 N/m, Screw Terminal, DIN Mount 35 Rail, IP20, IP30, -25 to 45 deg C, 78.8 mm Height, 22.5 mm Width, 109 mm Depth

Key Specifications

SKU	S&SRZ7-FSL3GA40
Brand	Sprecher+Schuh
Range Name	RZ7-FSL3
Product Type	Time Delay Relays

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Rugged construction and high level of timing accuracy established through rigorous design and testing Various timing ranges from 0.05 seconds to 60 hours allowing fine control of switching requirements
Standard Pack Size	1
UNSPSC Class	39122300
UOM	EA
Vendor Product	RZ7FSL3GA40
Contact Configuration	1 Changeover
Current	1 mA
Depth	109 mm
Height	78.8 mm
Mounting Method	DIN Rail
IP Rating	IP20/30
Operating Cycles	30000000 Mechanical/200000 Electrical Cycles
Power Rating	5 VA AC/0.5 Watt DC
Temperature	-25 to 45 deg C
Tightening Torque	0.8-1.2 N/m
Terminal Connection	Screw
Timing Function	Function L Impulse Converter
Timing Range	30 Seconds-10 Minutes
Voltage	346-440 Volt AC
Width	22.5 mm
