Forked Spade Insulated DGrip 0.5-1.5mm M6 Stud Red

Product Code
PANEV18-14FB-Q
Std Pack Size
25

You need to be registered and logged in to view product details and pricing

Description

Forked Spade Terminal, Insulated, Double Grip, 0.5-1.5 mm Conductor, M6 Stud, Standard Terminal, 600 Volt Maximum, Wire Strip Length: 6.8 mm, Funnel Barrel, Butted Seam, Crimping Die: KST2000A, Free Hanging, Copper Body, Copper Conductor, Vinyl Insulation, Red Insulation, Tin Plated Finish, 221 deg F, 21.1 mm Overall Length, 11.2 mm Lug Length, 9.4 mm Lug Width, 0.8 mm Lug Thickness, 6.35 mm Lug Inside Width, Barrel Length: 9.9 mm, Max. Insulation Diameter: 3.7 mm, 25 Pack
Forked Spade Terminal, Insulated, Double Grip, 0.5-1.5 mm Conductor, M6 Stud, Standard Terminal, 600 Volt Maximum, Wire Strip Length: 6.8 mm, Funnel Barrel, Butted Seam, Crimping Die: KST2000A, Free Hanging, Copper Body, Copper Conductor, Vinyl Insulation, Red Insulation, Tin Plated Finish, 221 deg F, 21.1 mm Overall Length, 11.2 mm Lug Length, 9.4 mm Lug Width, 0.8 mm Lug Thickness, 6.35 mm Lug Inside Width, Barrel Length: 9.9 mm, Max. Insulation Diameter: 3.7 mm, 25 Pack

Additional Information

Additional Information
Brand Panduit
Range Name StrongHold
Standard Pack Size 25
UNSPSC Class 39121400
UOM EA
Vendor Product EV18-14FB-Q
Voltage Rating 600 Volt
Body Material Copper
Barrel Length 9.9mm
Barrel Type Funnel
Lug Width 9.4mm
Conductor Size 0.5-1.5mm
Conductive Material Copper
Wire Strip Length 6.8 mm
Finish Tin Plated
Lug Thickness 0.8mm
Insulation Colour Red
Insulation Material Vinyl
Lug Length 11.2mm
Pack Size 25 Pack
Insulation Diameter 3.7mm
Product Type Forked & Ring Terminals
Seam Type Butted
Crimping Die KST2000A
Overall Length 21.1mm
Mounting Method Free Hanging
Terminal Type Standard
Temperature 221 deg F
Stud Size M6 Stud
Lug Inside Width 6.35mm
