Katko Safety Isolating Switch Surface Mounting 4P 25A 400-690V Light Grey/Black IP66

Description

Safety Isolating Switch Surface Mounting, 400-690 Volt AC, 25 Amp, 50/60 Hz, 4 Pole, Aluminium, Light Grey Enclosure/Black Handle, IP66, Legend: ON OFF, Surface Mount, 1.5 to 16 mm, 157 mm Height, 102.5 mm Width, 116 mm Depth, -40 to 80 deg C

Key Specifications

Barcode (EAN-13)	9321807123152
SKU	NHPISO425MG
Brand	Katko
Product Type	Isolating Switches

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	IP65/IP66 rating combined with selection of polycarbonate, aluminium and stainless steel, has any environment, indoor or outdoor, covered Easy to install and operate Choice of larger enclosures for increased wiring space Door interlock when switch is in ON position preventing the unauthorized removal of the enclosure cover for added safety Dedicated ISO TUFF series for arduous industry with 316 stainless steel enclosure and handle with flat roof and sloped roof options to keep accumulation of dirt and other contaminants off the switch LK10 and LK11 handles used on the ISO series are padlockable for added security Snap-on accessories couldn’t be any easier or quicker to install
Standard Pack Size	1
UNSPSC Class	39122200
UOM	EA
Vendor Product	ISO425MG
Colour	Light Grey/Black Handle
Current	25 Amp
Frequency	50/60 Hz
Depth	116 mm
Height	157 mm
IP Rating	IP66
Legend	ON OFF
Mounting Method	Surface
Number Of Poles	4 Pole
Voltage	400-690 Volt
Width	102.5 mm
Terminal Capacity	1.5-16 mm
Temperature	-40 to 80 deg C
