Maxim Model EHS Rotating Mirror Beacon Red 12 V H1 Halogen 12 VDC IP55
Loading...
Description
Industrial Beacon Rotating Mirror, 12 Volt DC, 4.7 Amp, 55 Watt, 12 Volt H1 Halogen Lamp, Flash Rate: 180 rpm, Through Base Connection, IP55, 30 deg Vertical, Metal Housing, Acrylic Lens, Red Lens, 148mm x 215mm
Key Specifications
| SKU |
MECMXEHS012R
|
|---|---|
| Brand |
Maxim
|
| Product Type |
Beacons & Strobes
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Features |
|
|---|---|
| Standard Pack Size | 1 |
| UNSPSC Class | 39111700 |
| UOM | EA |
| Vendor Product | MXEHS012R |
| Connection Type | Through Base |
| Current | 4.7 Amp |
| Dimensions | 148 mm x 215 mm |
| Flash Rate | 180 rpm |
| Housing Material | Metal |
| IP Rating | IP55 |
| Lamp Type | 12 Volt H1 Halogen |
| Lens Colour | Red |
| Lens Material | Acrylic |
| Voltage | 12 Volt DC |
| Wattage | 55 Watt |
