Hobson Sleeve Anchor Flush Head 12x75mm 316 Stainless Steel

Description

Sleeve Anchor Flush Head, 12 mm, M10 Thread, 15mm Width Head, 20.3mm Washer Diameter, 75mm Length, 60mm Min Drill Depth, 12mm Drill Diameter, 316 Stainless Steel, 14mm Fixture Hole Diameter, 100mm Min. Concrete Thickness, 75mm Min. Edge Distance, 75mm Min. Spacing, Torque Rating: 40 N-m

Key Specifications

Barcode (EAN-13)	9314818502436
SKU	HOBMTH16PM120075
Brand	Hobson

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Simple installation through object to be fastened Variety of diameters & lengths to suit different applications Low costs on supply and installation Can be immediately used
Standard Pack Size	25
UNSPSC Class	31162100
UOM	EA
Vendor Product	MTH16PM120075
Drill Diameter	12mm
Drill Depth	60mm Min
Diameter	12mm
Finish	316 Stainless Steel
Fixture Hole Diameter	14mm
Head Size	15mm Width
Head Type	Flush
Minimum Concrete Thickness	100mm
Minimum Edge Distance	75mm
Minimum Spacing	75mm
Product Type	Sleeve Anchor Flush Head
Thread Size	M10
Torque Rating	40 N-m
Washer Diameter	20.3mm
