Heinelec Combination RCD Circuit Breaker RCBO 2Pole 16 Amp 110 to 240V 10 kA DIN Rail Surface

Description

Combination RCD Circuit Breaker RCBO, 16 Amp, 110 to 240 Volt, 50/60 Hz, Interrupt Capacity: 10 kA, Trip Sensitivity: 500 mA, Number of Poles: 2, 0.75 to 35 mm Terminal Connection, Shrouded Line and Load, IP2X, DIN Rail, Surface,-40 to 85 deg C, 119.5mm Height, 80mm Width, 64.6mm Depth

Key Specifications

SKU	HEISM15A16-500
Brand	Heinelec
Product Type	Combination RCBO

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Provides 30mA residual current protection Switches both the active and neutral poles Hydraulic-magnetic RCD Overcurrent trip point unaffected by ambient temperature Immune to pulsating DC 100% rating capability independent of amibent temperature Precision tripping characteristics Three pole plus switched netural each leakage protection switches all active and neutral each leakage protection switches all active and neutral poles Immune to pulsating DC load current Reset immediately after overload
Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	SM15A16-500
Current	16 Amp
Connection Type	Shrouded Line and Load
Depth	64.6 mm
Height	119.5 mm
Frequency	50/60 Hz
IP Rating	IP2X
Interrupt Capacity	10 kA
Mounting Method	DIN Rail/Surface
Number Of Poles	2 Pole
Terminal Connection	0.75-35 sq-mm
Temperature	-40 to 85 deg C
Voltage	110-240 Volt
Trip Sensitivity	500 mA
Width	80 mm
