Hager Switch Flush Mount Rocker Large 2 Gang 10A 250V 2 Way Horizontal White

Description

Switch Large, 250 Volt, 10 Amp, 2 Gang, Horizontal, Mounting Centres: 84 mm, Flush Mount, Terminal Capacity: 4 x 1.5 mm, Actuator Type: Rocker, 2 Way, Screw Connection, UV-Stabilized Polycarbonate, White, Glossy Finish, 117 mm Height, 77 mm Width, 16 mm Depth

Key Specifications

Barcode (EAN-13)	3250617009713
SKU	HAGWBSH2
Brand	Hager
Range Name	Hagerblu Premiere
Product Type	Switches Large Plate

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Rocker features in-built arc shield and chemical resistant pivots All plates fitted with 16AX mechanisms suitable for fluorescent loads 2 way and loop terminal as standard Combination head screws Phillip’s number 1 backed off for ease of cable insertion Terminals accommodate 4 x 1.5 sq-mm cable Multiple mounting holes No mechanism push back High impact high gloss UV stabilised polycarbonate construction
Standard Pack Size	1
UNSPSC Class	39122200
UOM	EA
Vendor Product	WBSH2
Colour	White
Actuator Type	Rocker
Connection Type	Screw
Current	10 Amp
Depth	16mm
Finish	Gloss
Height	117mm
Material	UV-Stabilized Polycarbonate
Mounting Centres	84 mm
Mounting Method	Flush
Number Of Gangs	2 Gang
Number Of Ways	2 Way
Orientation	Horizontal
Terminal Capacity	4 x 1.5 sq-mm
Voltage	250 Volt
Width	77mm
