Hager Combination RCD Circuit Breaker RCBO 1P+N 10 Amp 230/240V AC 10 kA 2Module 36mm DIN Rail

Description

Combination RCD Circuit Breaker RCBO Type A, 10 Amp, 230/240 Volt AC, 50 Hz, Interrupt Capacity: 10 kA, Trip Sensitivity: 10 mA, Magnetic Rating: 5/10 In, Number of Poles: 1P + N, Number of Modules: 2, 36mm Module Width, Trip Characteristic: C Curve, 1-16 mm Flexible/1-25 mm Rigid Terminal Connection, Screw, IP20, DIN Rail, 86mm Height, 35mm Width, 68mm Depth

Key Specifications

Barcode (EAN-13)	3250611011835
SKU	HAGACA560T
Brand	Hager
Product Type	Combination RCBO

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	ACA560T
Current	10 Amp
Connection Type	Screw
Depth	68 mm
Height	86 mm
Frequency	50 Hz
IP Rating	IP20
Interrupt Capacity	10 kA
Modules	2 Module 36 mm
Mounting Method	DIN Rail
Number Of Poles	1 Pole
Terminal Connection	1-16 sq-mm Flexible / 1-25 sq-mm Rigid
Trip Characteristic	C Curve
Voltage	230-240 Volt
Trip Sensitivity	10 mA
Width	35 mm
