Elko Contactor DIN AC3 40A 230VAC/DC 2NO-2NC 3 Pole DIN Rail/Panel Mount

Description

DIN Contactor, 230 Volt AC/DC Coil Voltage, 40 Amp AC3 AC3 Rating, 40 Amp AC1 AC1 Rating, 2 Normally Opened/2 Normally Closed Configuration, 4 Pole, 3 Phase Phase, DIN Rail Mounting, IP20, -5 to 55 deg C, 84 mm Height, 53.3 mm Width, 60 mm Depth

Key Specifications

Barcode (EAN-13)	8595188121477
SKU	ELOVS440-22
Brand	Elko
Product Type	Contactors DIN

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	For VS425, VS440, VS463, an auxiliary contact VSK-11 or VSK-20 can be mounted on the side of the module
Standard Pack Size	1
UNSPSC Class	39121500
UOM	EA
Vendor Product	VS440-22/230V
AC3 Rating (Amps)	40 Amp AC3
AC1 Rating (Amps)	40 Amp AC1
Contact Configuration	2 Normally Opened/2 Normally Closed
Depth	60 mm
Height	84 mm
IP Rating	IP20
Mounting Method	DIN Rail
Number Of Poles	4 Pole
Operating Coil Voltage	230 Volt AC/DC
Phase	3 Phase
Temperature	-5 to 55 deg C
Width	53.3 mm
