Efector Proximity Switch Inductive Sensing Unshielded Flush M18 10-30VDC PNP 1NO M12 Plug

Description

Proximity Switch Inductive Sensing Unshielded Flush, Sensing Range: 5 mm, PNP, 10-30 Volt DC, <10 mA, M12 Plug, NO, LED, Flush Mount, IP67, Brass White Bronze Coated PBT, -25 to 80 deg C, Length: 50 mm

Key Specifications

SKU	EFFIG5495
Brand	Efector
Product Type	Proximity Sensors

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Robust metal housing for use in harsh industrial environments Wide operating temperature range Very high switching frequency Clearly visible indication of the switching status High protection rating for the requirements of harsh industrial environments
Standard Pack Size	1
UNSPSC Class	39122200
UOM	EA
Vendor Product	IG5495
Connection Type	M12 Plug
Current	<10 mA
Contact Configuration	Normally Opened
Display	LED
IP Rating	IP67
Material	Brass White Bronze Coated PBT
Output Function	PNP
Operating Voltage	10-30 Volt DC
Mounting Method	Flush
Sensing Range	5 mm
Temperature	-25 to 80 deg C
