Crouse Hinds Metal Cable Gland Armoured General Purpose 10.2-15.8mm M20 IP66/67

Description

Metal Cable Gland, Armoured, General Purpose, M20, 14 mm Thread Length, 10.2 mm Min. Sheath OD, 15.8 mm Max. Sheath OD, 11 mm Max. Bedding OD, 0.9 mm Min. Armour Wire, 1.25 mm Max. Armour Wire, 27 mm Width Across Flats, 31 mm Width Across Corners, IP66/67, Brass Body, Nickel Plated Finish

Key Specifications

Barcode (EAN-13)	9323952097074
SKU	CRUTWA1M16
Brand	Crouse Hinds
Range Name	Terminator TWA
Product Type	Cable Glands Metal

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Armour clamping and bonding for steel wire armoured cable Forms weatherproof seal on outer sheath of cable
Standard Pack Size	1
UNSPSC Class	39121400
UOM	EA
Vendor Product	TWA1M16
Body Material	Brass
Finish	Nickel Plated
IP Rating	IP66/67
Max. Armour Wire	1.25 mm
Max. Bedding OD	11 mm
Min. Armour Wire	0.9 mm
Min. Sheath OD	10.2 mm
Max. Sheath OD	15.8 mm
Thread Length	14 mm
Thread Size	M20
Width Across Corners	31 mm
Width Across Flats	27 mm
