Clipsal Switch Flush Mount Rocker Standard 5 Gang 10A 250V 1 Pole 1/2 Way Horizontal Black
Loading...
Description
Switch Standard, 250 Volt AC, 10 Amp, 1 Pole, 5 Gang, IP66, Horizontal, Mounting Centres: 84 mm, Flush Mount, Terminal Capacity: 4 x 1.5 mm, Actuator Type: Rocker, 1/2 Way, Screw Connection, Plastic, Black, Glossy Finish, 76 mm Height, 116 mm Width, 30 mm Depth
Key Specifications
| Barcode (EAN-13) |
9311554381141
|
|---|---|
| SKU |
CLIC2035HABK
|
| Brand |
Clipsal
|
| Range Name |
Classic C2000 Series
|
| Product Type |
Switches Standard
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Features |
|
|---|---|
| Standard Pack Size | 1 |
| UNSPSC Class | 39122200 |
| UOM | EA |
| Vendor Product | C2035HA-BK |
| Colour | Black |
| Actuator Type | Rocker |
| Connection Type | Screw |
| Current | 10 Amp |
| Depth | 30mm |
| Finish | Gloss |
| Height | 76mm |
| IP Rating | IP66 |
| Material | Plastic |
| Mounting Centres | 84 mm |
| Mounting Method | Flush |
| Number Of Gangs | 5 Gang |
| Number Of Poles | 1 Pole |
| Number Of Ways | 1/2 Way |
| Orientation | Horizontal |
| Terminal Capacity | 4 x 1.5 sq-mm |
| Voltage | 250 Volt |
| Width | 116mm |
