Clipsal Actassi S-110 Outlet Mechanism Modular Jack Cat5e UTP RJ45 30 Mech T568A/B White Shutter

Description

Outlet Mechanism Cat5e UTP, 1000 Volt AC/DC, 1.5 Amp, 24-23 AWG, RJ45 Connector, Cat5e UTP Cable, 8 Pins, >= 500 MOhm at 100 Volt DC Insulation Resistance, 20 mOhm Contact Resistance, 750 Cycles Durability, 1-100 MHz Bandwidth, Wiring Scheme: TIA-568A/B, S-110 30 Mech Outlet Mechanism, Flammability: UL94-V0, ABS + PC Housing, Copper Alloy Contact Base, Gold Plated Contact Plating, White,-10 to 60 deg C, 36mm Length, 22mm Height, 16mm Width

Key Specifications

Barcode (EAN-13)	3606489823139
SKU	CLI30RJ45SMA5SHCWE
Brand	Clipsal
Range Name	RJ45

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	43223300
UOM	EA
Vendor Product	30RJ45SMA5SHC-WE
Cable Type	Cat5e UTP
Colour	White
Conductor Size	24-23 AWG
Connector	RJ45
Contact Plating Material	Gold Plated
Contact Base Material	Copper Alloy
Contact Resistance	20 mOhm
Current	1.5 Amp
Durability	750 Cycles
Flammability	UL94-V0
Frequency Bandwidth	1-100 MHz
Height	22mm
Housing Material	ABS + PC
Insulation Resistance	>= 500 MOhm at 100 Volt DC
Number of Pins	8 Pin
Outlet Type	S-110 30 Mech
Temperature	-10 to 60 deg C
Voltage	1000 Volt AC/DC
Width	16mm
Wiring Scheme	TIA-568A/B
