Contactor General Purpose DC Operated, 48 Volt DC, AC3 Rating (kW): 11, AC3 Rating (Amps): 25 at 440 Volt AC, AC1 Rating (Amps): 40 at 440 Volt AC, 690 Volt AC, 300 Volt DC, 1NO-1NC Auxiliary, 3 Pole, Operating Time: 65.45-88.55 ms Closing, 20-30 ms Opening, Screw Clamp, DIN Rail/Plate Mount, IP20, -40 to 60 deg C, 85 mm Height, 45 mm Width, 101 mm Depth
Additional Information
Brand | Schneider |
---|---|
Range Name | TeSys Model D |
Standard Pack Size | 1 |
UNSPSC Class | 39121500 |
UOM | EA |
Vendor Product | LC1D25EL |
AC1 Rating (Amps) | 40 Amp AC1 |
AC3 Rating (Amps) | 25 Amp AC3 |
AC3 Rating (kW) | 15 kW |
Contact Configuration | 1 Normally Opened & 1 Normally Closed Aux |
Contact Voltage | 690 Volt AC/300 Volt DC |
Height | 85 mm |
IP Rating | IP20 |
Depth | 101 mm |
Number Of Poles | 3 Pole |
Mounting Method | DIN Rail/Plate |
Operating Coil Voltage | 48 Volt DC |
Operating Time | 65.45-88.55 ms Closing/20-30 ms Opening |
Temperature | -40 to 60 deg C |
Product Type | Contactors General |
Width | 45 mm |
Terminal Connection | Screw Clamp |
