B&R Meter Box Victoria 20 Pole W485mm H430mm D278mm DIN Mount Steel Galvanised

Description

Meter Box Victoria, Service Facilities: 1 Phase, 20 Poles, 430mm Height, 485mm Width, 278mm Depth, 380mm Panel Height, 400mm Panel Width, Padlock Lock, IP23, DIN, Steel, RAL 7035, Galvanised

Key Specifications

Barcode (EAN-13)	9321228084667
SKU	B&RV5
Brand	B&R
Product Type	Meter Boxes Domestic

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	SIR Approval #SIR140615B Designed for both single and multi-phase installations Provides safety, quality and performance Suitable for domestic and light commercial metering applications Easy-to-use gravity catch Ratchet sliding cable entry RotaDIN rotating/removable DIN section Cord retainer for easy retention of extension cords Identification with covered labelling section Weatherproof installation label for AS/NZS3000 compliance
Standard Pack Size	1
UNSPSC Class	39121100
UOM	EA
Vendor Product	V5
Enclosure Depth	278mm
Enclosure Width	485mm
Enclosure Height	430mm
Panel Height	380mm
Panel Width	400mm
Lock Type	Padlock
Colour	RAL7035 Grey
Finish	Galvanised
Number Of Poles	20 Pole
Mounting Method	DIN Rail
Material	Steel
Service Facilities	1 Phase
IP Rating	IP23
