Wideband Fibre Optic Distribution Cable Singlemode Indoor/Outdoor 12 Fibre PVC Black
Loading...
Description
Fibre Optic Distribution Cable Singlemode Indoor/Outdoor, Fibre Optic Cable Indoor/Outdoor Single Mode 12 Core, Loaded: 134mm, Installed: 67mm Bend Radius, Fibre Count: 12, Single Mode Fibre, Short Term: 660 N, Long Term: 300 N Max. Tensile Load, PVC Sheath, Black Sheath,-10 to 60 deg C, 6.7mm Outside Diameter
Key Specifications
| SKU |
WIDDIMXKR12BK
|
|---|---|
| Brand |
Wideband
|
| Product Type |
Fibre Optic Distribution
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Features |
|
|---|---|
| Standard Pack Size | 50 |
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | DIMXKR12BK |
| Bend Radius | Loaded: 134mm/Installed: 67mm |
| Fibre Count | 12 |
| Fibre Mode | Single Mode |
| Max. Tensile Load | Short Term: 660 N/Long Term: 300 N |
| Outside Diameter | 6.7mm |
| Sheath Colour | Black |
| Sheath Material | PVC |
| Temperature | -10 to 60 deg C |
